Antares PWM frequency conversion MODULEX UPMH 25-60-180 Circulating Pump, 230V

Antares PWM frequency conversion MODULEX UPMH 25-60-180 Circulating Pump, 230V

ANTARES MODULEX UPMH 25-60-180 circulating pump is a smart frequency conversion circulator with integrated differential pressure electronic control, with the option to set the regulation module and the head (differential pressure). Differential pressure is regulated by the pump speed.

▸ Universal circulating pump for every application ▸ Universal circulating pump for every replacement ▸ Smart frequency conversion circulating pump with electronic control of:
● PP – Proportional Pressure
● CP – Constant Pressure
● CS – Constant Speed
● Self Adapt – Automatic control ▸

Complies with European directives Eup/Erp with energy efficiency index ≤ 0.21. ▸ Equipped with PWM1 and PWM2 controller for parametrizable external regulation. ▸ Structural quality: rotating parts made of ceramic bearings, wear-resistant.

Head mt. 1-6
MAX. flow rate. 3.2 m³/h
Thread Ø : 1 1/2” M.
Length: 180 mm (without connection fittings)
Connection Fittings: 11/2’’Fx 1’’M included

• Liquid temperature: 2°C ~ 110°C
• Room temperature: 0°C ~ 40°C
• Max. system pressure: 10 bar
• Protection level: IP44
• Rated voltage/frequency: 220 V ~ 240 V / 50 Hz
• Insulation class: E
• Features of the pumped liquid: clean, free from solids and mineral oils, nontoxic, chemically neutral, 50 % glycol antifreeze
• Installation: the motor shaft must be kept in the horizontal direction
